描述
The Nova 2-in-1 video processor TU20 Pro is a professional LED display controller that combines video processing and playback in a single unit. With custom Android 11, dual-band Wi-Fi, wireless screen casting and up to 3.9 million pixels of loading capacity, it is built for conference rooms, control rooms and commercial displays that need flexible, network-based content management.
Inputs & Outputs
| HDMI inputs | 2 × HDMI 1.3 |
| USB | 3 × USB 2.0, adaptable for multimedia playback and feature expansion |
| Ethernet outputs | 6 × Gigabit Ethernet, supporting up to 3.9 million pixels |
| Audio outputs | 1 × S/PDIF digital audio output and 1 × 3.5 mm analogue audio output |
| Scaling output | Width 64–4096, height 64–1920, load capacity up to 3.9 million pixels (max 2.88 million pixels per port) |
System Functions
- Custom Android 11 UI with support for third-party apps
- Wireless screen casting across Windows, macOS, iOS and Android; screen-mirroring app for real-time mirror control
- Quad-core ARM Cortex-A55 processor up to 1.8 GHz
- H.264 4K@30 Hz and H.265 4K@60 Hz video decoding
- 4 GB RAM and 32 GB internal storage
- Dual Wi-Fi — simultaneous connection to a Wi-Fi network and a Wi-Fi hotspot
Playback & Visual
- Outstanding playback: 2 × 4K, 5 × 1080p, 5 × 720p, 8 × 480p or 10 × 360p video playback
- Mobile app intelligent playback, remote control playback and USB standalone plug-and-play
- Free routing — no software fees and no configuration limits
- One-touch eye protection mode
- Standard, conference, vivid and portrait scene modes with custom brightness, colour temperature, saturation and contrast
- Gigabit Ethernet control port with TCP/IP, external infrared remote wake-up, low power standby below 0.5 W and cascade power management
Technical Specifications
| Input voltage | DC 12 V 3 A (positive polarity externally, negative polarity internally) |
| Rated power | 21 W |
| RAM | 4 GB |
| Internal storage | 32 GB |
| Operating environment | −20 °C to 50 °C; 0–80% RH non-condensing |
| Storage environment | −20 °C to 70 °C; 0–95% RH non-condensing |
| Dimensions | 211.7 × 185.0 × 50.6 mm |
| Net weight | 1.12 kg |
| Gross weight | 2.9 kg |
| Package dimensions | 387.0 × 359.0 × 173.0 mm |
In the Box
1 × TU20 Pro, 1 × power adapter, 1 × Bluetooth voice remote control, 1 × network cable, 1 × HDMI cable, 3 × antennas, 2 × mounting ears, 2 × CR2025 batteries, 1 × QR code card, 1 × certificate of approval.
FAQ
Q: What does “2-in-1” mean on the TU20 Pro?
A: It combines a video processor and a playback controller in one unit. Instead of pairing a separate processor, a sending card and a media player, the TU20 Pro scales and processes the incoming signal and drives the screen directly, while also storing and playing content on its own — one box for processing, playback and network control.
Q: How much screen can the TU20 Pro drive?
A: It provides 6 × Gigabit Ethernet outputs supporting up to 3.9 million pixels in total, with a maximum of 2.88 million pixels per port. With scaling enabled, the output range is 64 to 4096 pixels wide and 64 to 1920 pixels high. For unusually large loads, please contact us or NovaStar Cloud technical support to confirm the configuration.
Q: Can presenters mirror their own laptop or phone wirelessly?
A: Yes. Wireless screen casting is supported across Windows, macOS, iOS and Android, and a companion screen-mirroring app provides real-time mirror control — useful in conference rooms where presenters switch sources from their own device. Dual Wi-Fi lets the unit stay connected to the network while simultaneously broadcasting its own hotspot.
Q: What can it play without an external computer?
A: The TU20 Pro plays 2 × 4K, 5 × 1080p, 5 × 720p, 8 × 480p or 10 × 360p video simultaneously, and supports mobile app playback, remote control playback and USB plug-and-play or file copying. It decodes H.264 4K@30 Hz and H.265 4K@60 Hz.
Q: What hardware powers it, and what are the power requirements?
A: A quad-core ARM Cortex-A55 processor running up to 1.8 GHz, with 4 GB RAM and 32 GB internal storage, on a custom Android 11 interface that supports third-party apps. Power input is DC 12 V 3 A with a rated power of 21 W and standby consumption below 0.5 W; the unit can also be woken by an external infrared remote.
Q: What is in the box, and where can it be installed?
A: The package contains 1 × TU20 Pro, 1 × power adapter, 1 × Bluetooth voice remote control, 1 × network cable, 1 × HDMI cable, 3 × antennas, 2 × mounting ears, 2 × CR2025 batteries, 1 × QR code card and 1 × certificate of approval. The unit measures 211.7 × 185.0 × 50.6 mm (net weight 1.12 kg), operates from −20 °C to 50 °C and stores from −20 °C to 70 °C at 0–80% RH non-condensing.
